Category:

Agriculture, Conveying, Industrial

Applications:

Water discharge at high pressure, for general industry and agriculture.

Properties:

High flexible layflat hose made with specially compounded high quality PVC and synthetic fiber reinforcement. Lightweight, easy to handle and requires minimal storage space. Excellent resistance to abrasion, water absorption and freezing temperatures. Bore smooth to minimize friction loss, exterior sinuous

Standard Colors:

Regular: Blue Heavy Duty: Red

Temperatures Range:

-10°C < Temp <60°C

layflat
layflat-2

Regular:

Item

Code

Size

mm (Inch)

Inside

Diameter

(mm)

Wall

Thickness

(mm)

Weight

(g/m)

Working

Pressure

Bar / 20°C

FLBH-100 25 ( 1″) 26  /   +/-1.0 1.50 / +/-0.20 165   /   +/-10.00 7.0
FLBH-125 32 ( 1.25″) 33  /   +/-1.0 1.45 / +/-0.20 200    /   +/-10.00 7.0
FLBH-150 40 ( 1.5″) 40 /   +/-2.0 1.45 / +/-0.30 230   /   +/-10.00 7.0
FLBH-200 50 ( 2″) 52 /   +/-2.0 1.60 / +/-0.30 333  /   +/-10.00 7.0
FLBH-250 65 ( 2.5″) 65.5  /   +/-2.0 1.70 / +/-0.30 430  /  +/-13.00 7.0
FLBH-300 75 ( 3″) 78  /   +/-2.0 1.90 / +/-0.30 570   /  +/-17.00 6.0
FLBH-400 100 ( 4″) 104 /   +/-2.0 2.30 / +/-0.30 865 /  +/-26.00 6.0
FLBH-600 150 ( 6″) 155 /   +/-2.0 2.60 / +/-0.30 1,482   /  +/-44.50 6.0
FLBH-800 200 ( 8″) 206 /   +/-2.0 2.65 / +/-0.30 2,020 /  +/-60.50 4.0

Heavy Duty

Item

Code

Size

mm (Inch)

Inside

Diameter

(mm)

Wall

Thickness

(mm)

Weight

(g/m)

Working

Pressure

Bar / 20°C

FLB-100 40 ( 1.5″) 40  /   +/-1.0 1.95 / +/-0.30 290 /  +/-10.00 10.5
FLB-200 50 ( 2″) 52.5  /   +/-1.0 2.05 / +/-0.30 420 /  +/-12.00 10.5
FLB-250 65 ( 2.5″) 66   /   +/-1.0 2.15 / +/-0.30 540  /  +/-16.00 10.5
FLB-300 75 ( 3″) 78.5  /   +/-1.0 2.55 / +/-0.30 660  /  +/-20.00 9.0
FLB-400 100 ( 4″) 104  /   +/-1.5 2.55 / +/-0.30 1,000 /  +/-30.00 9.0
FLB-600 150 ( 6″) 155  /   +/-1.5 2.95 / +/-0.30 1,680 /  +/-50.00 7.0
FLB-800 200 ( 8″) 207  /   +/-1.5 2.95 / +/-0.30 2,200 /  +/-60.00 5.0
